Your Current Location: Homepage> Products> Wheel Loader>SEM668D
SEM668D

SEM668D

Advantages

Product Advantages

Reliability: Sturdy frame design for heavy duty, Caterpillar design transmission and made in house axle make usage life longer

Productivity: EH control transmission with KD and auto speed function, optimized TC and engine match 11% rimpull improved

Fuel consumption: Optimized transmission flow and E-fan deliver lower fuel consumption Comfortable: Good visibility cab low noise design with first class premium 6 directions adjustable seat make comfortable operation

Inquiry
Features Specification Photo

Multiple Applications

  • Landscaping, building, sewer/water tie-in, local utility construction
  • Ready mix cement/concrete products, quarry/stone, clay, recycled aggregate, sand and gravel Highway, street, tunnel, airport, residential commercial
  • Item
    Unit
    Params
  • Main Specifications
  • Rated Load
    kg
    6,000
  • Operating Weight with Standard Bucket
    kg
    20,117
  • Bucket Capacity
    m³
    2.9-5.5
  • Wheel Base
    mm
    3,350
  • Overall Dimension
    mm
    8,541*3,092*3,458
  • Max. Drawbar Force
    KN
    188
  • Breakout Force
    KN
    197
  • Dump Clearance
    mm
    3,051
  • B-Pin Height
    mm
    4,196
  • Transmission
  • Transmission Type

    Countershaft, Powershift, EH Control
  • Transmission Gears

    F4/R3
  • Torque Converter Type

    Single Stage, 3 Elements
  • Maker & Type

    SEM160
  • Forward I/Reverse I

    6.3/6.3
  • Forward II/Reverse II

    11/11
  • Forward III/Reverse III

    19.6/19.6
  • Forward IV/Reverse IV

    32/NA
  • Axle
  • Main Drive Type

    Spiral Bevel Gear, Single Stage
  • Final Drive Reduction Type

    Planetary Type, Single Stage
  • Rear - Oscillating +/-

    ±11
  • Engine
  • Model

    Weichai WD10G240E201
  • Rated Power

    178
  • Rated Speed
    r/min
    2,200
  • Displacement
    L
    9.7
  • Implement Hydraulic
  • Implement System Type

    Open Center
  • Boom Raise Time
    s
    5,33
  • Hydraulic Cycle Time
    s
    9.85
  • System Pressure Setting
    Mpa
    18
  • Brake System
  • Service Brake

    Dry&Caliper, Air to Oil Control
  • Parking Brake

    Drum/Shoe
  • Steering System
  • System Type

    Shared Flow
  • Steering Pump Type

    Gear Pump
  • System Pressure Setting
    Mpa
    16
  • Steering Angle (L/R)

    38±1
  • Tires
  • Size

    23.5-25
  • Type

    Bias
  • Layer

    20
  • Textured Type

    L-3
